China E320D2 C7.1 engine assy

Engine type: 6-cylinder, turbocharged, aftercooled diesel engine
Displacement: 7.01 liters
Bore x Stroke: 105 mm x 135 mm
Compression ratio: 16:1
Power output: 129 kW (173 hp) at 1,800 rpm
Torque: 949 Nm at 1,400 rpm
Emissions level: Tier 4 Final, Stage V
Cooling system: Water-cooled with belt-driven fan and radiator
Fuel system: Common rail fuel injection system with high-pressure fuel pump, fuel injectors, fuel filter and water separator
Lubrication system: Forced-feed lubrication with full-flow oil filter, oil cooler and oil pressure switch
Electrical system: 24V electrical system with starter motor and alternator
Dimensions (L x W x H): 1,190 mm x 945 mm x 1,036 mm
Weight: 791 kg (dry weight)
