SAA6D107E-1:
Engine type: 6-cylinder, water-cooled, direct-injection diesel engine
Displacement: 6.69 liters
Bore x Stroke: 107 mm x 124 mm
Compression ratio: 17.2:1
Power output: 123 kW (165 hp) at 2,000 rpm
Torque: 800 Nm at 1,500 rpm
Emissions level: Tier 3
Cooling system: Water-cooled with belt-driven fan and radiator
Fuel system: Common rail fuel injection system with high-pressure fuel pump, fuel injectors, fuel filter and water separator
Lubrication system: Forced-feed lubrication with full-flow oil filter, oil cooler and oil pressure switch
Electrical system: 24V electrical system with starter motor and alternator
Dimensions (L x W x H): 1,155 mm x 718 mm x 1,059 mm
Weight: 540 kg (dry weight)
QSB6.7:
Engine type: 6-cylinder, water-cooled, direct-injection diesel engine
Displacement: 6.7 liters
Bore x Stroke: 107 mm x 124 mm
Compression ratio: 17.3:1
Power output: 145 kW (194 hp) at 2,200 rpm
Torque: 980 Nm at 1,500 rpm
Emissions level: Tier 3
Cooling system: Water-cooled with belt-driven fan and radiator
Fuel system: Common rail fuel injection system with high-pressure fuel pump, fuel injectors, fuel filter and water separator
Lubrication system: Forced-feed lubrication with full-flow oil filter, oil cooler and oil pressure switch
Electrical system: 24V electrical system with starter motor and alternator
Dimensions (L x W x H): 1,215 mm x 826 mm x 1,011 mm
Weight: 590 kg (dry weight)
