OEM R450LC-7 R500LC-7 1NB-01010 11NB-04010 engine assy

R450LC-7 R500LC-7 1NB-01010 11NB-04010 engine assy
Peak torque (R450LC-7): 1,250 lb-ft (1,695 Nm) at 1,300 RPM
Peak torque (R500LC-7): 1,400 lb-ft (1,900 Nm) at 1,300 RPM
Emissions compliance: EPA Tier 3 and EU Stage IIIA
Weight (dry): 1,620 kg (3,571 lbs)

Get a Quote -?>

DESCRIPTION

Configuration: Inline 6-cylinder, 4-stroke diesel engine
Displacement: 12.7 liters (774 cubic inches)
Bore: 130 mm (5.12 inches)
Stroke: 157 mm (6.18 inches)
Compression ratio: 16.5:1
Aspiration: Turbocharged and aftercooled
Fuel system: High-pressure common rail with electronic controls
Governor: Electronic
Cooling system: Liquid-cooled
Lubrication system: Gear-driven pump with full-flow and bypass filtration
Electrical system: 24-volt DC
Engine management system: Hyundai electronic control system
Here are some additional specifications for these engine assemblies:

Maximum power output (R450LC-7): 325 horsepower (242 kW) at 1,800 RPM
Maximum power output (R500LC-7): 387 horsepower (288 kW) at 1,800 RPM
Peak torque (R450LC-7): 1,250 lb-ft (1,695 Nm) at 1,300 RPM
Peak torque (R500LC-7): 1,400 lb-ft (1,900 Nm) at 1,300 RPM
Emissions compliance: EPA Tier 3 and EU Stage IIIA
Weight (dry): 1,620 kg (3,571 lbs)
